Copper conductor, EPR Insulation, Copper Tape Screen with aluminium welded corrugated armoured and PVC Sheath

Symbol    :    MV-105 MC-HL 35kV or CU/EPR/CTS/MC/PVC

Identification of Cores :

Phase:Identification by PE Tape ( Black, Red, Blue )
  Other specification are available on request

Symbol    :    MV-105 MC-HL 35kV or CU/EPR/CTS/MC/PVC

Applicable Standard  :Rated Voltage : 35 kV
Specification:IEC 60502-2
ICEA 60502-2
UL 1072
  Other Specification are available on request
Application :* Indoor and outdoor ( wet or dry location )
* Branch circuit for power distribution system
* Installation direct burial
* Installation cable tray
* Approved for classes I, II and III division 1 and 2, class 1, zones 1 and 2
