Copper conductor, XLPE insulation with aluminium welded corrugated armoured and PVC sheath

Identification of Cores Phase :

Twin-cores:Black, Red
Three-cores :Black, Red, Blue
Four-cores:Black, Red, Blue, Orange
Five-cores:Black, Red, Blue, Orange, Brown
Above Five-cores:Black with White Numbering
Grounding:Uninsulated or Green with Yellow Stripe
  Other colours are available on request

Symbol    :    XHHW-2 MC-HL or CU/XLPE/MC/PVC

Applicable Standard  :Rated voltage: 0.6/1kV
Specification:IEC 60502-1
ICEA S-95-658/NEMA WC70
NEC Table 250.122
UL 44
Other Specification are available on request
Application :*Indoor and outdoor ( wet or dry location)
*Branch circuits for power,lighting, control and signaling
*As aereal cable on a messenger
*Installation direct burial
*Installation cable tray
*Approved for classes I,II and III Division 1 and 2, class 1, zones 1 and 2
